渤海湾盆地济阳坳陷古近系全油气系统特征与成藏模式
高阳(1982-),男,山东滨州人,博士,中国石油化工股份有限公司胜利油田分公司勘探开发研究院副研究员,主要从事常规—非常规油气勘探部署等工作。地址:山东省东营市东营区聊城路2号,中国石化胜利油田分公司勘探开发研究院,邮政编码:257015。E-mail:gaoyang565.slyt@sinopec.com |
Copy editor: 谷江锐
收稿日期: 2024-01-18
修回日期: 2025-05-10
网络出版日期: 2025-05-13
基金资助
国家科技重大专项“渤海湾超级盆地油气富集规律与新领域勘探技术”(2024ZD1400101)
中国石油化工股份有限公司项目“东部富油气凹陷及周缘资源评价”(P23234)
Geological characteristics and hydrocarbon accumulation model of the whole petroleum system in Paleogene of Jiyang Depression, Bohai Bay Basin, China
Received date: 2024-01-18
Revised date: 2025-05-10
Online published: 2025-05-13
基于胜利油田大量基础研究和实验分析资料,以全油气系统理论为指导,系统剖析渤海湾盆地济阳坳陷古近系沉积体系分布、烃源岩分布及生排烃特征、储层物性变化和断裂系统控藏作用,研究断陷盆地全油气系统地质特征;以东营凹陷为解剖对象,结合已发现常规油气、致密油气和页岩油气分布,总结断陷盆地断控复合全油气系统成藏模式,梳理横向和纵向分布的大型地质体内常规和非常规油气分布规律。研究表明:①古气候和构造旋回控制济阳坳陷古近系沉积体系的有序分布,多期次发育的烃源岩为页岩油气原位聚集及油气运聚成藏提供了充足的物质来源,储层物性变化控制了油气成藏动力门限,不同期次的断裂组合控制了油气运聚成藏和页岩油气原位滞留聚集规模,使得断陷盆地全油气系统具有关联性、分隔性和突变性,上述要素相互配置形成了济阳坳陷古近系断控复合全油气系统。②受成藏动力控制,一个全油气系统可以划分为常规油气子系统和非常规油气子系统,纵横向上从页岩油、致密油到常规油有序分布。上述规律性地质认识对中国东部陆相断陷盆地全油气系统分析具有一定的借鉴意义。
高阳 , 刘惠民 . 渤海湾盆地济阳坳陷古近系全油气系统特征与成藏模式[J]. 石油勘探与开发, 2025 , 52(3) : 551 -562 . DOI: 10.11698/PED.20240034
Based on a large amount of basic research and experimental analysis data from Shengli Oilfield, Bohai Bay Basin, guided by the theory of whole petroleum system, the distribution of sedimentary systems, the distribution and hydrocarbon generation and expulsion process of source rocks, the variation of reservoir properties, and the control of fracture systems on hydrocarbon accumulation in the Paleogene of the Jiyang Depression, Boahai Bay Basin, were systematically analyzed, and the geological characteristics of the whole petroleum system in the fault basin were identified. Taking the Dongying Sag as an example, combined with the distribution of discovered conventional, tight, and shale oil/gas, a hydrocarbon accumulation model of the fault-controlled whole petroleum system in fault basin was proposed, and the distribution patterns of conventional and unconventional oil and gas reservoirs in large geological bodies horizontally and vertically were clarified. The research results show that paleoclimate and tectonic cycles control the orderly distribution of the Paleogene sedimentary system in the Jiyang Depression, the multi-stage source rocks provide sufficient material basis for in-situ shale oil/gas accumulation and other hydrocarbon migration and accumulation, the changes in reservoir properties control the dynamic threshold of hydrocarbon accumulation, and the combination of faults and fractures at different stages controls hydrocarbon migration and accumulation, and in-situ retention and accumulation of shale oil/gas, making the whole petroleum system in the fault basin associated, segmented and abrupt. The above elements are configured to form a composite whole petroleum system controlled by faults in the Paleogene of the Jiyang Depression. Moreover, under the control of reservoir-forming dynamics, a whole petroleum system can be divided into conventional subsystem and unconventional subsystem, with shale oil, tight oil and conventional oil in an orderly distribution in horizontal and vertical directions. This systematic understanding is referential for ananlyzing the whole petroleum system in continental fault basins in eastern China.
[1] |
赵文智, 何登发, 范土芝. 含油气系统术语、研究流程与核心内容之我见[J]. 石油勘探与开发, 2002, 29(2): 1-7.
|
[2] |
胡朝元, 廖曦. 成油系统概念在中国的提出及其应用[J]. 石油学报, 1996, 17(1): 10-16.
|
[3] |
|
[4] |
|
[5] |
|
[6] |
|
[7] |
|
[8] |
|
[9] |
|
[10] |
赵文智, 何登发, 池英柳, 等. 中国复合含油气系统的基本特征与勘探技术[J]. 石油学报, 2001, 22(1): 6-13.
|
[11] |
|
[12] |
|
[13] |
金之钧, 张一伟, 王捷, 等. 油气成藏机理与分布规律[M]. 北京: 石油工业出版社, 2003.
|
[14] |
魏恒飞, 李秋媛, 毕建军, 等. 论烃源岩层系含油气系统[J]. 大庆石油地质与开发, 2020, 39(6): 1-12.
|
[15] |
贾承造, 郑民, 张永峰. 非常规油气地质学重要理论问题[J]. 石油学报, 2014, 35(1): 1-10.
|
[16] |
贾承造. 论非常规油气对经典石油天然气地质学理论的突破及意义[J]. 石油勘探与开发, 2017, 44(1): 1-11.
|
[17] |
|
[18] |
贾承造, 庞雄奇, 宋岩. 全油气系统理论基本原理[J]. 石油勘探与开发, 2024, 51(4): 679-691.
|
[19] |
贾承造, 庞雄奇, 郭秋麟, 等. 基于成因法评价油气资源: 全油气系统理论和新一代盆地模拟技术[J]. 石油学报, 2023, 44(9): 1399-1416.
|
[20] |
宋振响, 周卓明, 江兴歌, 等. 常规-非常规油气资源一体化评价方法: 基于全油气系统理论和TSM盆地模拟技术[J]. 石油学报, 2023, 44(9): 1487-1499.
|
[21] |
姜福杰, 郭婧, 庞雄奇, 等. 渤海湾盆地南堡凹陷全油气系统3类油气资源联合评价[J]. 石油学报, 2023, 44(9): 1472-1486.
|
[22] |
唐勇, 雷德文, 曹剑, 等. 准噶尔盆地二叠系全油气系统与源内天然气勘探新领域[J]. 新疆石油地质, 2022, 43(6): 654-662.
|
[23] |
支东明, 李建忠, 杨帆, 等. 准噶尔盆地吉木萨尔凹陷二叠系全油气系统地质特征与勘探开发实践[J]. 中国石油勘探, 2023, 28(4): 14-23.
|
[24] |
彭光荣, 庞雄奇, 徐帜, 等. 珠江口盆地陆丰南地区古近系全油气系统特征与油气藏有序分布[J]. 地球科学, 2022, 47(7): 2494-2508.
|
[25] |
张赫, 王小军, 贾承造, 等. 松辽盆地北部中浅层全油气系统特征与油气成藏聚集模式[J]. 石油勘探与开发, 2023, 50(4): 683-694.
|
[26] |
曹正林, 张本健, 杨荣军, 等. 川西地区上三叠统须家河组全油气系统成藏模式新认识[J]. 天然气工业, 2023, 43(11): 40-53.
|
[27] |
姜福杰, 贾承造, 庞雄奇, 等. 鄂尔多斯盆地上古生界全油气系统成藏特征与天然气富集地质模式[J]. 石油勘探与开发, 2023, 50(2): 250-261.
|
[28] |
刘惠民, 李军亮, 刘鹏, 等. 济阳坳陷古近系页岩油富集条件与勘探战略方向[J]. 石油学报, 2022, 43(12): 1717-1729.
|
[29] |
陈建渝, 熊书权, 毕研鹏, 等. 断陷盆地中含油气系统的特征[J]. 石油学报, 2000, 21(2): 36-41.
|
[30] |
宋国奇. 含油气盆地成藏组合体理论初步探讨[J]. 油气地质与采收率, 2002, 9(5): 4-7.
|
[31] |
宋岩, 贾承造, 姜林, 等. 全油气系统内涵与研究思路[J]. 石油勘探与开发, 2024, 51(6): 1199-1210.
|
[32] |
刘惠民, 高阳, 秦峰, 等. 渤海湾盆地济阳坳陷油气勘探新领域、新类型及资源潜力[J]. 石油学报, 2023, 44(12): 2141-2159.
|
[33] |
胡朝元. 生油区控制油气田分布: 中国东部陆相盆地进行区域勘探的有效理论[J]. 石油学报, 1982, 3(2): 9-13.
|
[34] |
胡见义, 徐树宝, 童晓光. 渤海湾盆地复式油气聚集区(带)的形成和分布[J]. 石油勘探与开发, 1986, 13(1): 1-8.
|
[35] |
刘兴材, 杨申镳. 济阳复式油气区大油田形成条件及分布规律[J]. 成都理工学院学报, 1998, 25(2): 276-284.
|
[36] |
李丕龙, 张善文, 宋国奇, 等. 济阳成熟探区非构造油气藏深化勘探[J]. 石油学报, 2003, 24(5): 10-15.
|
[37] |
张善文. 中国东部老区第三系油气勘探思考与实践: 以济阳坳陷为例[J]. 石油学报, 2012, 33(增刊1): 53-62.
|
[38] |
李丕龙, 张善文, 宋国奇, 等. 断陷盆地隐蔽油气藏形成机制: 以渤海湾盆地济阳坳陷为例[J]. 石油实验地质, 2004, 26(1): 3-10.
|
[39] |
宋明水, 李友强. 济阳坳陷油气精细勘探评价及实践[J]. 中国石油勘探, 2020, 25(1): 93-101.
|
[40] |
王永诗. 济阳坳陷不同领域油气勘探思路与方向[J]. 油气地质与采收率, 2021, 28(5): 1-12.
|
[41] |
宋明水. 济阳坳陷勘探形势与展望[J]. 中国石油勘探, 2018, 23(3): 11-17.
|
[42] |
庞雄奇, 李素梅, 金之钧, 等. 排烃门限存在的地质地球化学证据及其应用[J]. 地球科学, 2004, 29(4): 384-390.
|
[43] |
金强, 朱光有. 中国中新生代咸化湖盆烃源岩沉积的问题及相关进展[J]. 高校地质学报, 2006, 12(4): 483-492.
|
[44] |
张林晔. 湖相烃源岩研究进展[J]. 石油实验地质, 2008, 30(6): 591-595.
|
[45] |
包友书, 张林晔, 张守春, 等. 用渗流法研究东营凹陷烃源岩压实排油特点[J]. 石油学报, 2008, 29(5): 707-710.
|
[46] |
王淼, 宋国奇, 王学军, 等. 东营凹陷咸化湖相纹层状烃源岩初次生排烃流体特征[J]. 中国石油大学学报(自然科学版), 2020, 44(2): 31-41.
|
[47] |
郭显令, 熊敏, 周秦, 等. 烃源岩生排烃动力学研究: 以惠民凹陷临南洼陷沙河街组烃源岩为例[J]. 沉积学报, 2009, 27(4): 723-731.
|
[48] |
赵明, 陈小明, 季峻峰, 等. 济阳坳陷古近系原型盆地中绿泥石的成分演化特征及其盆地古地温梯度[J]. 中国科学: 地球科学, 2007, 37(9): 1141-1149.
|
[49] |
庞雄奇, 贾承造, 宋岩, 等. 全油气系统定量评价: 方法原理与实际应用[J]. 石油学报, 2022, 43(6): 727-759.
|
[50] |
王永诗, 郝雪峰, 安天下, 等. 盆地结构控制下的地层压力-流体-储集性协同演化及控藏作用: 以东营凹陷古近系为例[J]. 石油学报, 2023, 44(7): 1058-1071.
|
[51] |
|
[52] |
邱桂强, 王居峰, 李从先. 东营凹陷沙三中东营三角洲地层格架与油气勘探[J]. 同济大学学报, 2001, 29(10): 1195-1199.
|
[53] |
王居峰, 邓宏文. 基山砂体层序地层特征及成因类型分析[J]. 油气地质与采收率, 2004, 11(3): 7-9.
|
/
〈 |
|
〉 |
